I just released version 0.6.1 of SLIDE, the PC<-->Beast serial file transfer tool.
This version of SLIDE brings it up to date with the latest version of the SLIDE Protocol spec. The headline item is the introduction of a "command channel" which allows your main computer to to send simple commands to the MicroBeast and get responses back, during a file transfer session. Currently those commands are:
VOLS - what volumes (drives) are present on the 'BeastDIR - what files are in a particular volume?REN - rename a fileDEL - delete a file
I know what you're thinking: all MicroBeasts have two drives but that might not always be the case!
These commands are mainly intended for use by impending BeasTTY features, but they're available right now in the command line helper tools:
VOL
./slide probe /dev/ttyUSB4 --start-cmd "slide r" --cmd vols
will get you:
SLIDE — command-channel probe (wire v0.3 §2)
Port: /dev/ttyUSB4 @ 19200 baud
Probe: ENQ 0x05, 3 attempt(s), 500ms echo timeout
Typing slide r at the CP/M prompt...
✓ Z80 connected. (46 stray byte(s) skipped, wakeup signature seen)
--- Probe result (after handshake) ---
Outcome: supported
Attempts: 1
Queued before probe: (none)
Stray bytes during probe window: (none)
VER raw: 30 30 30 31 ('0001')
Version: major 0, minor 1
We speak: major 0, minor 1
--- CMD_VOLS ---
Status: 0x00 — ST_OK
Present: A: B:
Logged: A: B:
Current: B:
--- FIN exchange (session-intact check) ---
FIN echoed. The peer was still in its file loop and exited
cleanly — the probe did not disturb the session.
VERDICT: probe outcome 'supported', session intact.
DIR
./slide probe /dev/ttyUSB4 --start-cmd "slide r" --cmd dir --drive a:
results in:
SLIDE — command-channel probe (wire v0.3 §2)
Port: /dev/ttyUSB4 @ 19200 baud
Probe: ENQ 0x05, 3 attempt(s), 500ms echo timeout
Typing slide r at the CP/M prompt...
✓ Z80 connected. (46 stray byte(s) skipped, wakeup signature seen)
--- Probe result (after handshake) ---
Outcome: supported
Attempts: 1
Queued before probe: (none)
Stray bytes during probe window: (none)
VER raw: 30 30 30 31 ('0001')
Version: major 0, minor 1
We speak: major 0, minor 1
--- CMD_DIR (A:) ---
Status: 0x00 — ST_OK
USER NAME ATTR BYTES
0 PIP.COM 7424
0 STAT.COM 5248
0 KCALC.COM 37504
0 SIEVE.COM 1792
0 MBASIC.COM 24320
0 ZORK1.COM 8704
0 ZORK1.DAT 84992
0 SLIDE.COM 2944
0 UPLOAD.COM 640
0 DOWNLOAD.COM 512
0 WRITE.COM 896
0 RESTORE.COM 768
0 SETOPTS.COM 512
0 VLOAD.COM 896
0 VPEEK.COM 896
--- FIN exchange (session-intact check) ---
FIN echoed. The peer was still in its file loop and exited
cleanly — the probe did not disturb the session.
VERDICT: probe outcome 'supported', session intact.
REN
./slide probe /dev/ttyUSB4 --start-cmd "slide r" --cmd ren --match=SLIDE.COM --to=SLIDE2.COM
results in:
SLIDE — command-channel probe (wire v0.3 §2)
Port: /dev/ttyUSB4 @ 19200 baud
Probe: ENQ 0x05, 3 attempt(s), 500ms echo timeout
Typing slide r at the CP/M prompt...
✓ Z80 connected. (46 stray byte(s) skipped, wakeup signature seen)
--- Probe result (after handshake) ---
Outcome: supported
Attempts: 1
Queued before probe: (none)
Stray bytes during probe window: (none)
VER raw: 30 30 30 32 ('0002')
Version: major 0, minor 2
We speak: major 0, minor 2
--- CMD_REN (current drive SLIDE.COM -> SLIDE2.COM) ---
Status: 0x00 — ST_OK
(no records — probe-only exchange completed)
--- FIN exchange (session-intact check) ---
FIN echoed. The peer was still in its file loop and exited
cleanly — the probe did not disturb the session.
VERDICT: probe outcome 'supported', session intact.
DEL
./slide probe /dev/ttyUSB4 --start-cmd "slide2 r" --cmd del --match=RESET.COM
gets you:
SLIDE — command-channel probe (wire v0.3 §2)
Port: /dev/ttyUSB4 @ 19200 baud
Probe: ENQ 0x05, 3 attempt(s), 500ms echo timeout
Typing slide2 r at the CP/M prompt...
✓ Z80 connected. (47 stray byte(s) skipped, wakeup signature seen)
--- Probe result (after handshake) ---
Outcome: supported
Attempts: 1
Queued before probe: (none)
Stray bytes during probe window: (none)
VER raw: 30 30 30 32 ('0002')
Version: major 0, minor 2
We speak: major 0, minor 2
--- CMD_DEL (current drive RESET.COM) ---
Status: 0x00 — ST_OK
(no records — probe-only exchange completed)
--- FIN exchange (session-intact check) ---
FIN echoed. The peer was still in its file loop and exited
cleanly — the probe did not disturb the session.
VERDICT: probe outcome 'supported', session intact.
As you can see, it's a little verbose: there's a lot of diagnostic information in there that we used during backwards compatibility testing.
We did a lot of backwards compatibility testing...but there are always gremlins lurking. If you're feeling helpful please adopt slide v0.6.1 as your daily driver and give it a whirl while we wait for the new BeasTTY features - let me know of any issues!
